Cheese processing production line

Pasteurisation tank

Material: SUS304

Power supply: 380v 50Hz

Power: 24kw

Installation size: 1300*1050*1900

Stirring motor: 0.37kw

Stirring speed: 36r/min

Working pressure: 0.09 Mpa

Material inlet and outlet calibre: φ38mm

cheese pot

Material: SUS304

Voltage: 380V

Heating power: 24kw

Stirring power: 0.75kw

Stirring speed: frequency conversion adjustable

Speed range: 0-36R/min

Inner liner diameter: 1000mm

Equipment size: 1600*1300*2100

milk pump

Voltage: 380V/three-phase/50hz

Flow rate: 1T/H

Material inlet and outlet: φ38

Power: 0.37kw

pipeline circulatory system

Equipment base

Stainless Steel Piping

Stainless steel elbow, tee

Stainless steel connection clamps, gaskets

Stainless steel manual quick release clamp butterfly valve

Presses

Material: SUS304

Single slot size: 400*300

Pneumatic double groove

whey separation tank

Material: SUS304

Size: 1500*800*1500
