Innovative Solid Bowl Decanter Centrifuge From Technology Leader

Availability:

Quantity:



Inquire Add to Basket

Model:
LW
Brand:
Shenzhou

Product Description

Operating principle:

3 Phase Horizontal Tricanter centrifuge

Tricanter centrifuge is a horizontal centrifuge with continuous feeding and continuous discharging. The settling speed is determined by particle size,particle shape,difference in density between solids and liquids as well as their viscosity.Decanter centrifuge is suitable for solid-phase dewatering, liquid-phase clarification and separation, liquid-liquid-solid three phase separation and size-grading of various suspensions with solid-phase particle sizes of 0.005-15mm, consistency of 1-40% and temperature of ≤ 100°C. It is used for oil-water-solid separation , Have good performance in olive oil , coconut oil ,palm oil avocado oil production line .

FEATURES AT A GLANCE

1.All parts coming into contact with the product are made of stainless steel

2.3-phase AC motor for controlled torque starting via frequency converter
3.Approximately 80 to 90% of the oil is recovered.
4.Low personnel costs due to continuous and automatic operation.
5.Highest g-force for higher solids output
6.Adjustable bowl speed via VFD
7.Automatic adjustment of differential speed via VFD
8.Two motor drive
9.Belts for both primary motor and secondary
10.NSK /SKF Bearing

Specification

Model	Diameter(mm)	Lenght(mm)	Max speed	L/D ratio	G-force	Capacity(m3/h)	Main motor power(Kw)	Weight(kg)	Dimension (mm)
LW250*1000	250	1000	5000	4	2722	0.5-5	7.5	950	21201250680
LW300*900	300	900	4200	3	2964	1-6	11	1160	21501300900
LW300*1200	300	1200	4000	4	2784	2-6	11	1350	24501300900
LW355*1160	355	1160	3600	3.3	2576	2-8	15	1400	24701350830
LW355*1460	355	1460	3600	4	2576	2-10	15	1800	27501350830
LW400*1200	400	1200	3200	3	2294	3-12	18.5	1800	273016001080
LW400*1600	400	1600	3000	4	2016	3-15	22	2000	313016001080
LW450*1800	450	1800	2800	4	1976	4-25	37	2500	332017001130
LW500*2000	500	2000	2800	4	1750	5-35	45	4000	352018001170
LW530*1855	530	1855	2600	3.5	2006	5-38	55	4680	388513501600
LW530*2120	530	2120	2400	4	1709	5-40	55	4800	415013501600
LW550*2000	550	2000	2800	4	2414	6-40	55	5700	457013801600
LW650*1950	650	1950	2200	3	1761	6-45	75	5000	484015101720
LW650*2600	650	2600	2000	4	1456	6-65	90	6000	549015101720
LW720*2160	720	2160	2000	3	1612	7-80	120	6000	520016001800
LW720*2880	720	2880	2000	4	1306	7-90	120	8000	310016001800
LW800*2400	800	2400	1800	3	1451	20-100	150	12000	582020001300
LW800*3200	800	3200	1800	4	1451	20-120	150	1300	710020001300

Contact: owen tang

Email: owen@lnszjx.com

Whatsapp:+8613130702388

Our services

•3 months long guarantee period from machine arriving date.

•Abundant spare parts in stock are available to provide.

•Our technicians could be dispatched for overseas service.

•24 hours technical consultation.

•Routine tracing till the machine work properly will be done timely.

•We will remind you to do the normal maintenance.

•Your suggestions or any comments & reflection would be treated in priority.

•Your workers can get training easily by net video.
